MAZAK VCU 500A/2PC
The VC-500A/2PC vertical 3-axis machining center includes a two-pallet changer that maximizes spindle utilization.
Including following standard equipment:
Spindles
MAIN SPINDLE MOTOR AC 20HP (15KW)/10- MIN SELECT SPINDLE SPEED BELOW
Magazines
30 TOOL MAGAZINE (CAT 40)
Workholding
19.68″ X 19.68″(500MM X 500MM) TABLE WITH TAPPED HOLES
2 PALLET CHANGER WITH SAFETY COVER
NOTE* INCLUDES COVER COOLANT STANDARD
Control
MAZATROL SMART CONTROL
10.4″ COLOR LCD
EIA/ISO CODE INPUT FUNCTION (STANDARD)
ADDITIONAL EIA/ISO FUNCTIONS (REQUIRES EIA/ISO)
The following EIA/ISO functions are included:
* SPIRAL INTERPOLATION (EIA)(G02.1/G03.I
* PATTERN ROTATION (EIA)
* 3-DIMENSIONAL CUTTER COMPENSATION (EIA)
* GEOMETRIC COMMAND (EIA)
* SCALING (EIA)(G50/G51)
* EXTERNAL DATA INPUT / OUTPUT (EIA)
USB I/F (1-PORT) / COMPACT FLASH READER
NOTE: THE USB PORT IS FOR DATA I/O FUNCTION ONLY (4GB)
THE FLASH CARD READER CAN BE USED TO DRIP FEED PROGRAMS, HOWEVER, YOU MUST PURCHASE
IC MEMORY CARD OPERATION. WITHOUT THIS OPTION THE
READER CAN ONLY BE USED FOR DATA I/O.
POLAR COORDINATES INPUT (G122) (EIA)
When programming a feature on the face of a part in EIA, this option in conjunction with Cylinder Option allows the programmer to use the axis letters X and C for programming a contour normally made using X and Y. The C takes place of the Y and makes creating the program very easy. Notes and Cautions: Polar coordinate input is available only in the mode of polar coordinate interpolation. You MUST purchase Cylinder option to allow the C axis to replace Y. If you do not the C will be the angle position of the feature. If the G122 command is given without selecting the mode of polar coordinate interpolation (by GI2.1), alarm will occur. G122 and G123 must be given in an independent block.
RELOCATION DEVICE
NOTE: RELOCATION DEVICE IS A PERMANENT BATTERY OPERATED
DEVICE THAT RESIDES IN THE ELECTRICAL CABINET OF THE
MACHINE. THIS DEVICE IS STANDARD FOR ALL MAZAK MACHINES AS AN EXPORT COMPLIANCE MEASURE TO PREVENT
ILLEGAL TRANSFERS AND MISAPPROPRIATIONS
WITHOUT THE PROPER GOVERNMENTAL AUTHORIZATION. THE DEVICE WILL SIGNAL AN ALARM AND COMPLETELY SHUT DOWN THE MACHINE
UPON ANY REPOSITIONING AND/OR RELOCATION OF THE
MACHINE. MAZAK REQUESTS THAT YOU CONTACT THE LOCAL MAZAK REPRESENTATIVE PRIOR TO ANY REPOSITIONING AND/OR RELOCATION OF THE MACHINE. THE MAZAK REPRESENTATIVE WILL VERIFY THE LOCATION OF THE MACHINE ACCORDING TO THE PROPER EXPORT ADMINISTRATION GUIDELINES AND ISSUE A NEW PASSWORD TO INITIATE STARTUP OF THE MACHINE.
Chip Control and Coolant
COMPLETE COOLANT SYSTEM (STD FLOOD, 64PSI)
COVER COOLANT (RECOMMENDED FOR CHIP-CONVEYOR)
Accessories
ABSOLUTE ENCODER SYSTEM
Miscellaneous
MAZAK STANDARD COLOR (FROST WHITE / 1 SATIN BLACK)
ROLLER GUIDE
X-AXIS TRAVEL 21.85″ (555MM)
Y AXIS TRAVEL 19.88″ (505MM)
OPERATOR DOOR INTERLOCK WITH LOCK-SWITCH
FULL COVERAGE CHIP AND COOLANT
GUARD WITHOUT TOP COVER
TOP COVER
WORK LIGHT (LED)
POWER TRANSFORMER FOR NORTH AMERICAN MARKET
STANDARD UNLIMITED PROGRAM
Note: OPTIONS INCLUDED
Spindles – Milling
SPINDLE SPEED 12000 RPM(CAT40) 25HP (18.5KW)/5 MIN GREASE
Control – Software
AUTO PECKING CYCLE WITH LOAD DETECTION
This option allows the control to continuously monitor the cutting load of the drill in use. By setting the threshold on the drill monitor display, the drill auto pecking cycle will execute the pecking process only when the machine torque exceeds the threshold level. Option #53 on control option page. Notes and Cautions: Auto pecking cycle helps prevent tool breakage and reduces machine down time. On a Matrix Mill control this option can be used with Mazatrol and EIA programs. On a Fusion 640M this option can only be used in Mazatrol. On a Matrix Lathe and Fusion 640T this option can ONLY be used in Mazatrol. Only for drill application.
Control – Software – General 3-Axis
SYNCHRONIZED TAPPING (G84.2 / G84.3)
This option allows rigid tapping on the turning spindle of a
lathe. Can be used in Mazatrol or EIA programs. This
synchronizes the main spindle with the z axis. Makes the use of
a floating tap holder unnecessary. In Mazatrol if you have this
option, it does not require any special codes. In EIA you will
utilize G84.2 rigid tapping cycle. Notes and Cautions: May
require spindle servo parameter optimization. Hole to be tapped must be on centerline with the chuck.
MAZACC-2D SOFTWARE (SHAPE COMPENSATION) (G61.1)
Option #14 – B) MAZACC-3 2D SOFTWARE (SHAPE COMP).
This function improves errors in control system by
implementing the appropriate acceleration/deceleration according to the particular machining contour, even for movement commands that require simultaneous control of the rotational axes. Notes and Cautions: Commonly used with GOS PI (High speed machining mode) and, K (Accuracy coefficient). Can also be used with; Inclined-plane machining mode? G68.2 P1. Polar coordinate interpolation? G12.1, Tool tip point control? G43.4. Tool radius compensation for 5-axis
machining? G41.5, Work piece error correction? G54.4, 3D Coordinate Conversion? G68. Not selectable with: Dynamic Offsetting II ? G54.2, Cylindrical Interpolation? G07.1, Sub Program Calls – G65 and G98, Tool Radius Comp – G41 and G42, Skip Function (measurement) G31 and threading. This is Option #14 on the control options page.
Chip Control and Coolant – Coolant
HI-PRESS.COOLANT THRU SPINDLE SYSTEM (15KGF,213PSI)
Chip Control and Coolant – Chip Conveyors
JORGENSEN HINGE CONVEYOR LEFT SIDE
DISP. (48″ DISCHARGE)
– Inverter type chip conveyors have automatic load sensors
that can reverse automatically to clear obstructions.
– Selectable conveyor speeds eliminate excessive coolant discharge.
High tech operation through selectable menu keys.
Less maintenance required.
Accessories – Part Probe
DUAL PROBING KIT OMP60/OTS AA W/EIA INSPECT PLUS
NOTE: INCLUDES RENISHAW 0M1-2T DUAL PROBE OPTICAL
RECIEVER, OMP60 OPTICAL PROBE (AA BATTERY), WIRELESS OTS-AA
TOOLSETTER. INSPECTION PLUSE SOFTWARE, AND ROTATING TOOL
SETTING SOFTWARE. FACTORY INSTALLED ONLY. THIS PACKAGE DOES NOT INCLUDE TRAINING FROM RENISHAW
*Specifications above are to be verified by purchaser*
Sunnen MBB-1290C Honing Machine
Specifications:
Diameter Range: .120″ to 2.625″
Length of Work Honed Depends on Diameter
Maximum Honing Length of 1/8″ Bore is 1 7/8″, while
Maximum Honing Length of 2 5/8″ Bore is 18″
Honing Speeds: 300, 450, 650, 850 RPM
Honing Speeds Via 4-Position Manually Adjustable Flat Belt Drive
Tool Socket Size: 1 3/4″ Diameter
Honing Oil System: Approx. 12 Gallon
Self Energizing Friction Spindle Brake
Manual Operation with Manual Cutting Pressure, Adjustment & Gage Dial
Foot Pedal Operation Control
Motor Pulley Cage Type Guarding
17″ x 24″ Flow Back Oil Tray with Side & Rear Splash Guards
Belt Driven Honing Oil Pump & Piping
1/2 HP Motor, 1 Phase, 115 Volts with On-Off Switch
Overall Dimensions: 32″ L-R x 39″ F-B x 58″ H
Approx. 800 Lbs.
Price: $4,250.00 As is, where is.
AGIECHARMILLES CUT 20P
# of Axis | 5 |
Table Size – L | 27.55 in |
Table Size – W | 18.89 in |
Table Load Capacity | 882 lb |
X – Axis Travel | 13.78 in |
Y – Axis Travel | 9.84 in |
Z – Axis Travel | 9.84 in |
U/V – Axis Travel | 1.77 in |
Auto Threading (Yes/No) | Yes |
Wire Diameter – Min | 0.004 in |
Wire Diameter – Max | 0.012 in |
Dielectric Tank Capacity | 211 gal |
Submerged (Yes/No) | Yes |
Chiller Included | yes |
Power Requirement | 380V/3PH/60Hz |
Control | CNC (Charmilles / Windows Control) |
Dimensions | 95″ x 79″ x 92″ tall |
Weight | 6,358 |
Price: $49,900.00 As is, where is.
MAS VR5A
MAS VR5A
Arm 1600mm
Weight 3,700 Kg
Spindle motor 4 kW – 28 – 2500 RPM
Spindle MT4
Clamping area 1800 x 1000
Max dia. in steel 50mm
Max dia. in cast iron 60mm
Max threading in steel M30
Max threading in cast iron M42
Distance table spindle nose 1600 mm
Price: $5,900.00 As is, where is.
Jones & Shipman Promat Cylindrical Grinder Model F15/450E
Serial Number: BO 18440 Manufactured: 1992
Allen Bradley 8600 CNC Control
Capacity
Maximum Diameter Ground 250mm
Distance between Centers 450mm
Centre Height 127mm
Maximum Weight Between Centers 100kgs
Workhead
Fixed base, dead centre type
Speed range 30 to 450rpm
(continuously variable) Centre 5MT
D.C Motor 1.1kW
Swivel angle + & – 15
Swivel encoder resolution (option) 0.001
Table (Z Axis)
Traverse Speed 0.06 to 120000mm/min
Min programmable increment 0.001
Servo input resolution 0.001mm
Table swivel + & – 16 & 18 degrees
Swivel encoder resolution (option) 0.001
Wheel heads (X axis)
Total in feed 205mm
Infeed speed 0.006 to 6000mm/min
Min programmable increment 0.001
Servo input resolution 0.001mm
Grinding Wheel Size 450mm x 50 x 127mm bore
Wheel speeds (2) 1400 & 1689rpm Motor 5.5kW
Complete with:
Paper Band Coolant filtration system
Manuals
Guarding
4-Wheel Arbors
Wheel Truing Arbor
Great Condition, Low Hours
Price: $34,500.00 As is, where is.
Specifications to be verified by purchaser
